The field of touch screen is developing rapidly, taking mobile phone touch screen as an example, the current mobile phone touch screen is still used in the traditional acrylic glue, the use of optical organic silicone is not common.
Adhesives/electromagnetic shielding electronic materials leader, Beginor Technology in the 5G era of communication equipment, smart phones and new energy vehicles and other fields have layout.
It includes semi-sintered chip bonding adhesive for 5G chip heat dissipation, high thermal conductivity gaskets for communication equipment, chat-level electromagnetic interference (EMI) shielding solutions, mobile phone camera module bonding protection materials, automotive cameras and vehicle-mounted radar bottom filling materials.
In handheld devices, Beginor Technology provides comprehensive solutions, such as: LCD touch screen full bonding, camera module assembly bonding, UBS waterproof seal, speaker seal, circuit board three anti-coating, power device heat dissipation, etc.
Model | Application point | Product type | Component | Curing condition | Solution |
MDGEL 6708 | LCD TP fully fit | Silicone | 2K | Room temperature/heat cure | Touch screen and LCD screen bonding |
MDGEL 6602 | LCD TP fully fit | Silicone | 2K | Room temperature/heat cure | Touch screen and LCD screen bonding |
MDSI 7102B-1-14 | TYPE C connector | Silicone | 1K | Room temperature | PIN pin is bonded and fixed |
MDEP 3225FR | Camera module | Epoxy | 2K | Room temperature/heat cure | The lens is bonded to the base |
MDEP 3112 | Speaker | Epoxy | 2K | Room temperature/heat cure | Internal device potting |
UV 2106D | Speaker | UV | 1K | UV curing | Adhesive for speaker ball top diaphragm bonding |
UV 2117D | Speaker | UV | 1K | UV curing | Speaker ball top center adhesive |
UV2107 | Speaker | UV | 1K | UV curing | Border bonding |
UV 2107 BF | Speaker | UV | 1K | UV curing | Lead fixing glue |
MDSI 7336W-TC | Power device heat dissipation | Silicone | 1K | Room temperature | mobile phone charging head |
MDTIM 6230 | Power device heat dissipation | Silicone | 1K | Room temperature/heat cure | mobile phone charging head |
MDTIM 6230#15 | Power device heat dissipation | Silicone | 1K | Room temperature/heat cure | mobile phone charging head |
MDCOAT 7060 | Circuit board three prevention | Silicone | 1K | Room temperature/heat cure | pcb board coating |
MDCOAT 721L | Circuit board three prevention | Silicone | 1K | Room temperature/heat cure | pcb board coating |
