MDSI 7001 Transparent silicone adhesive

Low viscosity and good flow type
High transparency and high physical and mechanical properties
Excellent insulation properties
It has the function of moisture-proof, dust-proof, anti-corona and anti-seismic buffering
Good high and low temperature resistance, temperature range of -60 ~ 250℃
Excellent aging resistance, service life of up to 20 ~ 30 years
After curing, the colloid does not yellow, does not permeate oil, and has excellent comprehensive performance

Product description

MDSI 7001 is a neutral dealcoholization bonding sealant with outstanding mechanical properties, non-corrosive to bonding materials, and has good bonding and sealing performance for most materials.

Data Sheet

Test items	Test standard	Units	MDSI 7001
Color	Visual	—	Translucent flowing
Viscosity	GB/T 2794-2013	25 ° C, mPa·s	4500-7500
Density	GB/T 13354-92	25C, g/cm³	1.02
Tack-free Time	GB/T13477.5-2002	25℃,55%RH,min	4-20
Hardness	GB/T 531.1-2008	Shore A	25 ± 3
Tensile strength	GB/T 528-2009	MPa	≥1.5
Shear strength	GB/T 6328-86	Mpa, Al/Al	≥0.8
Elongation at break	GB/T 528-2009	%	≥180
Dielectric strength	GB/T 1693-2007	kV/mm (25 ° C)	20
Loss factor	GB/T 1693-2007	(1MHz) (25 ° C)	0.009
Dielectric constant	GB/T 1693-2007	(1MHz) (25 ° C)	2.8
Volume resistance	GB/T 1692-92	(DC500V) Ω· cm	2.00E +14

Widely used in hard or flexible electronic lines, can also be used as thicker film circuit coating protection and porous products, such as moisture protection of ceramic products, can also be applied to solar equipment manufacturing.

How to use

Use of technology

Clean the surface: Clean the sticky or coated surface, and remove rust, dust, oil, etc.
Sizing: unscrew (or cut) the cap of the hose, squeeze the glue liquid to the cleaned surface, make it evenly distributed, and close the adhesive surface to fix it.
Curing: Place the glued or sealed part in the air and let it cure naturally. The curing process is a curing process from the surface to the inside. In 24 hours (room temperature and 55% relative humidity), the glue will cure to a depth of 4mm, and in 48 hours, it will cure to nearly 6mm.
If the sizing position is deep, especially the part that is not easy to reach the air, the full curing time will be extended, and if the temperature is low, the curing time will also be extended.
