MDCOAT 7007 80 Shore A Silicone conformal coating

Single component room temperature silicone
Curing can also be promoted by heating
Medium viscosity, suitable for brush, spray, dip coating a variety of processes
After curing to form a certain hardness, anti-wear transparent elastic protective film
It has good adhesion to various circuit boards
Good resistance to high and low temperature and flame retardant performance

Product description

MDCOAT 7007 is an organosilicone resin triple-resistant material for surface coating of electronic components, which is suitable for the environment with a temperature of -60-200℃. This product is suitable for PCB board surface coating, insulation, moisture, water and rust, bright and smooth surface, high mechanical strength, highly transparent paint film, anti-leakage, shock, dust, corrosion, anti-aging, corona resistance and other properties.

In addition, the coating protective film is also conducive to the line and components of friction resistance, solvent resistance, and can release the pressure caused by periodic changes in temperature. It can fully protect the wire panel in a variety of chemical corrosion, salt spray, moisture, high pollution and dust, vibration and high and low temperature and other harsh environment without affecting its work and signal.

Data Sheet

Item	MDCOAT 7007
Color	Transparent
Features	Flowing liquid
Curing method	Cure at room temperature or with heat
Viscosity (mPas)	800±100
Specific gravity (g/cm3)	1.05-1.10
Solid content (%)	70±2
Warranty period (months)	12
Surface cure (25 ° C 75%RH) for min	< 15
Warm surface curing time (60~80℃ 50%RH) min	3-5
Full hardening time (25 ° C 50%RH) H	24
Electrical/mechanical properties (cure for 7 days at temperature 25℃ humidity 75%)
Hardness (shore A)	≥80
Applicable temperature range (C)	-60 – 200
Linear expansion coefficient (DMA, -65~25℃, 5℃/min)	2.58 x 10-4
Dielectric strength (kv/mm) IPC-TM-650	≥16
Dielectric constant (1.2MHz))	2.8
Volume Resistance (Ohm/cm) IPC-TM-650	≥1.0×10¹⁵

Application

Hybrid integrated circuits
Automotive electronic control panel
Electronic circuit boards
Aviation instrumentation
Flexible printed circuit boards
Computer control panel
Industrial control board
Semiconductor crystal line protection
Appliance controller
Outdoor LED display

How to use

Curing process

The typical curing process for 3mil (0.075mm) thickness coating is curing at room temperature for 10min and drying at 80℃ for 10min. If there are bubbles in the coating, it needs to be left at room temperature for a longer period of time until the bubbles are eliminated before heating curing.

Operation process

Before coating, it is necessary to remove dust, moisture (moisture) and oil from the surface of the object to be coated and keep it dry.
This product can be applied by brush, spray, dip coating and other methods of construction. The coating is limited to no flow and no leakage. The thickness of a coating film is generally between 0.1-0.3mm. According to the selected coating process, the appropriate solvent can be selected to dilute the paint before use.
After the first coating is dry, the second coating can be applied.
The used brush, spray gun, etc. should be washed in time to prepare for the next use.
