MDSI 7002 Transparent silicone adhesive

Low viscosity and good flow type
High physical and mechanical properties
It has excellent insulation properties
It has the function of moisture-proof, dust-proof, anti-corona and anti-seismic buffering
Good high and low temperature resistance, temperature range of -60 ~ 220℃
Excellent aging resistance, service life of up to 20 ~ 30 years
After curing, the colloid does not yellow, does not permeate oil, and has excellent comprehensive performance
In line with food grade certification and environmental protection certification

Product description

MDSI 7002 is a neutral adhesive sealant with outstanding mechanical properties, no corrosion to bonding materials, and has good bonding and sealing performance for most materials, low odor and low white fog, high temperature resistance, oil resistance to oil transformer, excellent acid and alkali resistance.

Data Sheet

Test items	Test standard	Units	7002 Transparent	7002 Black
Color	Visual	—	Colorless translucent fluid	Black semi-flowing
Viscosity	GB/T 2794-2013	25℃, mPa·s	20,000-40,000	50,000±10,000
Density	GB/T 15223-1994	25℃, g/cm3	1.05±0.05	1.15±0.05
Tack-free Time	GB/T13477.5-2002	25℃,55%RH,min	≤10	10-30
Hardness	GB/T 531-2008	Shore A	30 ± 5	20 ±5
Tensile strength	GB/T 528-2009	MPa	≥1.8	≥2.0
Shear strength	GB/T 6328-86	Mpa, Al/Al	≥1.5	≥1.5
Elongation at break	GB/T 528-2009	%	≥200	≥400
Dielectric strength	GB/T 1693-2007	kV/mm (25 ° C)	≥20	≥20
Loss factor	GB/T 1693-2007	(1MHz) (25 ° C)	0.09	0.09
Dielectric constant	GB/T 1693-2007	(1MHz) (25 ° C)	2.8	2.8
Volume resistance	GB/T 1692-92	(DC500V) Ω· cm	2.00E +14	2.00E +14

Application

LED lamp seal, plastic metal shell seal; PCB board components, wiring harness fixed
Coatings for electronic accessories, electrical appliances and communication equipment

How to use

Use process:

Clean the surface: will be glued or coated surface clean, and remove rust, dust and oil.
Sizing: unscrew (or cut) the cap of the hose, squeeze the glue liquid to the cleaned surface, make it evenly distributed, and close the adhesive surface to fix it.
Curing: Place the glued or sealed part in the air and let it cure naturally. The curing process is a curing process from the surface to the inside. In 24 hours (room temperature and 55% relative humidity), the glue will cure to a depth of 4mm, and in 48 hours, it will cure to nearly 8mm.
If the sizing position is deep, especially the part that is not easy to reach the air, the full curing time will be extended, and if the temperature is low, the curing time will also be extended.
